将特征贡献可视化为条形图

将先前计算的特征贡献可视化为条形图。

lgb.plot.interpretation(
  tree_interpretation_dt,
  top_n = 10L,
  cols = 1L,
  left_margin = 10L,
  cex = NULL
)

参数

tree_interpretation_dt

由 lgb.interprete 返回的 data.table。

top_n

在图中包含的最大顶部特征数量。

cols

布局的列号，仅用于多类别分类的特征贡献。

left_margin

(base R 条形图) 允许调整左边距大小以适应特征名称。

cex

(base R 条形图) 作为 cex.names 参数传递给 barplot。

返回值

lgb.plot.interpretation 函数创建一个 barplot。

详情

该图将每个特征表示为一个水平条，其长度与特征的定义贡献成比例。特征按贡献递减的顺序列出。

示例

# \donttest{
Logit <- function(x) {
  log(x / (1.0 - x))
}
data(agaricus.train, package = "lightgbm")
labels <- agaricus.train$label
dtrain <- lgb.Dataset(
  agaricus.train$data
  , label = labels
)
set_field(
  dataset = dtrain
  , field_name = "init_score"
  , data = rep(Logit(mean(labels)), length(labels))
)

data(agaricus.test, package = "lightgbm")

params <- list(
  objective = "binary"
  , learning_rate = 0.1
  , max_depth = -1L
  , min_data_in_leaf = 1L
  , min_sum_hessian_in_leaf = 1.0
  , num_threads = 2L
)
model <- lgb.train(
  params = params
  , data = dtrain
  , nrounds = 5L
)
#> [LightGBM] [Info] Number of positive: 3140, number of negative: 3373
#> [LightGBM] [Info] Auto-choosing row-wise multi-threading, the overhead of testing was 0.000739 seconds.
#> You can set `force_row_wise=true` to remove the overhead.
#> And if memory is not enough, you can set `force_col_wise=true`.
#> [LightGBM] [Info] Total Bins 232
#> [LightGBM] [Info] Number of data points in the train set: 6513, number of used features: 116
#> [LightGBM] [Warning] No further splits with positive gain, best gain: -inf
#> [LightGBM] [Warning] No further splits with positive gain, best gain: -inf
#> [LightGBM] [Warning] No further splits with positive gain, best gain: -inf
#> [LightGBM] [Warning] No further splits with positive gain, best gain: -inf
#> [LightGBM] [Warning] No further splits with positive gain, best gain: -inf

tree_interpretation <- lgb.interprete(
  model = model
  , data = agaricus.test$data
  , idxset = 1L:5L
)
lgb.plot.interpretation(
  tree_interpretation_dt = tree_interpretation[[1L]]
  , top_n = 3L
)

# }
